describe
This is a wire or Litz wire wrapped with a Mylar or tapes
made from different material and a certain overlap
rate.
Specification range
Overlapping: 50%, 67%, 75%
Number of strands: From 1 up to 36000
Overall diameter:0.25～6mm
Wire sizes: From 0.02mm up to 0.50mm
Heat resistance grade
Product Standards
characteristic
• Good performance for high frequency application
• High insulation strength
• High thermal performance
• High resistance to radiation （PI tape)
application
Transformers required for high interlayer discharge voltage, motor, transformer and meter with requirements for high resistance to temperature and radiation.
